Description
Description
After the highly successful launch of the DIRECTION sound processors (EISA Award for the D68SP ), ESX is now taking the next step with the QUANTUM QM66SP. The new 6-channel processor is integrated into a high-quality aluminium heat sink and comes with even better standard equipment. Thanks to the integrated Bluetooth receiver, the app version of the ESX DSP Toolkit can be operated live and in real time from your smartphone - HD audio streaming included. The LCD remote control RC-DQ , available as an accessory, provides additional ease of use.
Thanks to the latest state-of-the-art A/D converters from AKM Velvet Sound™, the sound processing of the 32-bit/295 MHz Analog Devices™ DSP chips takes place in the Full HD audio range at 96 kHz. In addition to audiophile aspects, smooth integration into modern vehicles has also been taken into account. An EPS PRO protection circuit and high-level inputs with automatic switch-on function (can be connected from 1 to 15 V or 15 to 40 V via a jumper) as well as balanced low-level RCA outputs with 6 V/RMS are integrated as standard. Sound tuning redefined...
Features
- Analog Devices™ DSP chip, 32-bit, 294 MHz, 96 kHz Full HD audio
- AKM Velvet Sound™ 32-bit A/D, 32-bit D/A signal converter
- HP/LP/BP at 6-48 dB, phase shift, delay correction 0 ~ 20 ms / 0.01 ms steps
- Up to 248 output equalizers, 120 input equalizers (PEQ/HSLF/LSLF) +/- 12 dB, 0.5 dB steps)
- Input mixer, subwoofer control, priority input mode for digital input signals
-
DSP control via ESX DSP Toolkit
- PC software for Microsoft ® Windows™ 10 or later - Input sensitivity: low level 1~6V/RMS, high level 1~15 or 15~45V/RMS
- Signal-to-noise ratio (A-weighted): analog input 106 dB, digital input 111 dB
- Distortion factor: Analog input < 0.0015%, Digital input < 0.0009%
-
Integrated Bluetooth® receiver with antenna for DSP control via app and Full HD audio streaming
Bluetooth version 5.0, profiles: A2DP/AVRCP, codecs: aptX, aptx LL, AAC, SBC - REM OUT function for external devices, MODE switching input for e.g. hoods (Preset Auto Switch)
- Optional accessories: RC-DQ (LCD remote control)
.
